| Description | Specification | Unit |
| Rated operating load | 5000 | kg |
| Bucket capacity | 2.5~4.5 | m³ |
| Machine weight | 16900 | kg |
| Dump clearance at maximum lift | 3150~3560 | mm |
| Reach at maximum lift | 1100~1190 | mm |
| Wheelbase | 2960 | mm |
| Tread | 2250 | mm |
| Height of hinge at maximum lift height | 4112 | mm |
| Working height(fully lifted) | 5510 | mm |
| Max.breakout force | 170 | kN |
| Hydraulic cycle time-raise | ≤6 | s |
| Total hydraulic cycle time | ≤10.5 | s |
| Min. turning radius over tyres | 5950 | mm |
| Articulation angle | 35 | ° |
| Gradeability | 28 | ° |
| Tyre size | 23.5-25-16PR |
|
| Overall machine dimension L×W×H | 7910×3016×3515 | mm |
| Model | WD10G220E21 |
|
| Rated Power | 162 | kW |
| Fuel Tank | 250 | L |
| Hydraulic Tank | 210 | L |
| Travel speed | Ⅰ-gear(F/R)
Ⅱ-gear(F/R) | 13/18 | km/h |
| 40 | km/h |
